Place of Origin:
CHINA
Brand Name:
SUNRAIN
Certification:
CE
Model Number:
KFDC-100/300A
Contact Us
Features
make the world cleaner
Product Parameters
| Model No. | KFDC-70/150A | KFDC-70/200A | KFDC-100/200A | KFDC-100/300A |
| Heating capacity (W) | 3250 | 3250 | 4800 | 4800 |
| Hot water yield (L/h) | 70 | 70 | 100 | 100 |
| Input power (W) | 814 | 814 | 1136 | 1136 |
| Rated current (A) | 3.9 | 3.9 | 5.3 | 5.3 |
| Max. input power (W) | 2650 | 2650 | 3500 | 3500 |
| Max. input current (A) | 12.3 | 12.3 | 16.2 | 16.2 |
| Starting current (A) | 16.0 | 16.0 | 22.0 | 22.0 |
| COP | 3.99 | 3.99 | 4.23 | 4.23 |
| Auxiliary electric heater (W) | 1500 | 1500 | 1500 | 1500 |
| Heating type | Fluorine Cycle | Fluorine Cycle | Fluorine Cycle | Fluorine Cycle |
| Refrigerant type | R410A | R410A | R410A | R410A |
| Noise (dB(A)) | ≤50 | ≤50 | ≤52 | ≤52 |
| Running ambient temperature (ºC) | -7~43 | -7~43 | -7~43 | -7~43 |
| Main Unit size (mm) | 680×250×440 | 680×250×440 | 780×300×545 | 780×300×545 |
| Packing size (mm) | 790*355*530 | 790*355*530 | 905x380x590 | 905x380x590 |
| N.W / G.W (KG) | 25/30 | 25/30 | 32/40 | 32/40 |
| Water tank Model | SX-150D | SX-200D | SX-200D | SX-300D |
| Water tank volume (L) | 150 | 200 | 200 | 300 |
| Water tank size (mm) | Φ440*1696 | Φ500*1716 | Φ500*1716 | Φ630*1555 |
| Packing size (mm) | 530*530*1730 | 610*610*1750 | 610*610*1750 | 700*700*1710 |
| N.W / G.W (KG) | 55/64 | 70/79 | 70/79 | 90/110 |
| Test Condition: Heating Capacity at Air 20°C/15°C, Water Temperature from 15°C to 55°C | ||||
| Product Line Name | Production Line Capacity | Actual Units Produced(Previous Year) |
|---|---|---|
| Heating & Cooling Heat Pump/Swimming Pool Heat Pump/All In One Heat Pump/Heat Pump Water Heater | Heating & Cooling Heat Pump/Swimming Pool Heat Pump/All In One Heat Pump/Heat Pump Water Heater: 100,000 Pcs / Month | confidential |
| Market | Revenue(Previous Year) | Total Revenue (%) |
|---|---|---|
| South America | confidential | 5.0 |
| Oceania | confidential | 5.0 |
| Western Europe | confidential | 10.0 |
| Domestic Market | confidential | 80.0 |
| Machine Name | Brand & Model No. | Quantity | Number of Year(s) Used | Condition |
|---|---|---|---|---|
| Laser Cutting Machine | Confidential | 5 | 5.0 | Acceptable |
| Automatic Shearing Line | Confidential | 1 | 5.0 | Acceptable |
| Bending Machine | Confidential | 8 | 5.0 | Acceptable |
| Punching Machine | Confidential | 8 | 5.0 | Acceptable |
| Spinning Machine | Confidential | 5 | 5.0 | Acceptable |
| Tapping Machine | Confidential | 3 | 5.0 | Acceptable |
| Powder Coating Line | Confidential | 1 | 5.0 | Acceptable |
| Cylinder Making Machine | Confidential | 4 | 5.0 | Acceptable |
| Crane | Confidential | 10 | 5.0 | Acceptable |
| Machine Name | Brand & Model No. | Quantity | Number of Year(s) Used | Condition |
|---|---|---|---|---|
| Rob Vaccum System | Confidential | 4 | 5.0 | Acceptable |
| Comprehensive Leak Testing Room | Confidential | 1 | 5.0 | Acceptable |
| Halogen Leak Testing Room | Confidential | 1 | 5.0 | Acceptable |
