Place of Origin:
CHINA
Brand Name:
SUNRAIN
Certification:
TUV
Model Number:
BLN-026TA1
Contact Us
R32 Heat Pump Water To Water 26KW WIFI Smart Control With TUV
| Model | BLN-026TA1 |
| Power supply V/Ph/Hz | 380-415/3/50 |
| Installation | Freestanding |
| Factory | Guangdong China |
Many heat pump water heaters (HPWHs) are two to three times as efficient as conventional electric water heaters and have lower running costs.
In case your water heater is over 10 years old, it is time to start planning well in advance! Replacing it with a SUNRAIN air source heat pump can help you avoid the hassle, stress, and expense of a failing water heater.
Heat generators can be employed for heating and for cooling ends. They are available in several models to cool in the heat of winter and to cover heating in the winter, subject to model availability.
Product Parameters
| Model | BLN-026TA1 | ||
| Power supply | V/Ph/Hz | 380-415/3/50 | |
| Performance Condition: Outdoor air 7℃ / 6℃, Inlet / Outlet water 30℃ / 35℃ | |||
| Heating | Capacity (min-max) | kW | 11.8 ~ 28.6 |
| Rated input(min-max) | kW | 2.9 ~ 6.2 | |
| SCOP | 4.36 | ||
| Performance Condition: Outdoor air 7℃ / 6℃, Inlet / Outlet water 50℃ / 55℃ | |||
| Heating | Capacity | kW | 11.8 ~ 28.8 |
| Rated input | kW | 3.8 ~ 8.1 | |
| SCOP | 3.69 | ||
| Performance Condition: Outdoor air 35℃ / 24℃, Inlet / Outlet water 12℃ / 7℃ | |||
| Cooling | Capacity | kW | 5.2 ~ 19.5 |
| Rated input | kW | 4.8 ~ 9.3 | |
| EER | 2.83 | ||
| Energy class (SCOP) | Outlet water temp. at 35C | A++ | |
| Outlet water temp. at 55C | A++ | ||
| Max input current | A | 20.0 | |
| Max input power | KW | 11.5 | |
| Compressor | Type - Quantity/System | Twin Rotary - 1 | |
| Refrigerant | Type | R32 | |
| Charged volume | kg | 5.5 | |
| Fan | Quantity | 2 | |
| Airflow | m3/h | 6000 | |
| Rated power | W | 85 | |
| Noise level | Heating | dB(A) | 50 |
| Cooling | dB(A) | 51 | |
| Water flow volume | m3/h | 3.5 | |
| Water piping connections | mm | DN32 Male | |
| Operating temperature range | Cooling | C | -5 - 48 |
| Heating | C | -30 - 48 | |
| DHW | C | -30 - 48 | |
| Outlet water temperature range | Cooling | C | 5 - 25 |
| Heating | C | 25 - 55 | |
| DHW | C | 40 - 55 | |
| Net dimensions (WxDxH) | mm | 1127×427×1560 | |
| Packed dimensions (WxDxH) | mm | 1150X500X1720 | |
| Net/Gross weight | kg | 160/178 | |
Sample Project
