Place of Origin:
CHINA
Brand Name:
SolarEast
Certification:
CE,TUV
Model Number:
YT-300TB2
Contact Us
Product Parameters:
| Model | YT-200TB2 | YT-250TB2 | YT-300TB2 | ||
| Power Supply | 220~240V~/1/50Hz | ||||
| Heating Capacity | W | 2800 | |||
| Rated Hot Water Production | L/h | 60 | |||
| Rated Power Input | W | 629 | |||
| Rated Current Input | A | 2.8 | |||
| COP | W/W | 4.45 | |||
| ElectricHeater | Rated Power Input | W | 2000 | ||
| Rated Current Input | A | 8.9 | |||
| Power Input Max. | W | 3000 | |||
| Current Input Max. | A | 13.3 | |||
| Refrigerant Type/Charge/GWP | / | R290/0.45kg/3 | |||
| CO₂ Equivalent | / | 0.00135t | |||
| Working Ambient temperature | ℃ | '-7~46 | |||
| Operation Pressure(Low Side) | MPa | 0.8 | |||
| Operation Pressure(High Side) | MPa | 3 | |||
| Maximum Allowable | MPa | 3 | |||
| Electrical Shock proof | / | I | |||
| IP Class | / | IP1 | |||
| Water Tank Capacity | L | 200 | 250 | 278 | |
| Water Piping Connections | In | 3/4 | |||
| Rated Working Pressure Of Tank | MPa | 0.8 | |||
| Air flow Rated | m³ | 450 | |||
| Unit Dimensions (W/H/D) | mm | 1650*φ620 | |||
| Shipping Dimensions (W/H/D) | mm | 1755*700*700 | |||
| Noise | dB(A) | 48 | |||
| Net Weight | kg | 95 | 105 | 115 | |
Output Water Temp. Up To 75℃
Power Consumption Module
Wifi Smart Control
Shipping & Packaging
Advanced Laboratory
With a $3 million investment, Solareast’s state-of-the-art laboratory replicates extreme environmental conditions (-30°C to 52°C) to rigorously test product performance and reliability. Certified by TUV and Intertek, the lab’s recent expansion includes water drawdown and explosion-proof testing facilities, further enhancing our quality and safety standards.
